    Best way to retain product’s freshness and preserve quality by packing harvested materials in a range of 25-50 kg bags.Our packing machines provide a significant contribution in the feeding animals by preserving materials’ longtime freshness and productivity so that  the expenses stemming from animal feed is minimized.

    - Feeding  bunker synchronised working with motor drivers.


    - Entegrated vertical intake auger provides direct transfer of materials from the bunker to the weight unit.



    - Accurate and Fast Weighing.



    - Two step filling system for fast filling and exact/accurate scaling.



    - Weighing and Filling Unit with movement sensor provides slowly and regular filling the materials and perceive the bags and

      move the bag holders,  save from time.



    - Entegrated bottom band  provides smoothly, fast transfering and easy use.



    - Strong press unit brings the packaged material’s smooth appearance, easy packing save from space.



    - Strong air suction ability with vacuum unit, absorb the air inside the bag.



    - Any kind of closing with : Hot sealing , sewing, clipping  up to user demand can be entegrated.



    - All system is operated by the electronic control panel or automation PLC .



    - Air Compressor supplies optimum air amount for all related units.



    - Remote Connection for technical support.

    Capacity 6-8 Ton/h Required Power 380 V
    Filling Range 25-50 kg/bag Mixer Capacity 4m³
    Power Consumption 12 Kw/h Mixer Dimension (LxWxH)  100x300x150 cm
    Filling Bunker Diameter Ø28 - Ø32 cm
